IR0280H Fever Detection Thermal Camera Dual Mode
-
Thermal Imaging Camera for Fever Detection
A true fever screening solution for all business sizes.
From schools, offices and restaurants, and various other venues, additional manpower is required to monitor and check individuals' temperature before they are allowed to enter. Operation costs are high and could be higher still if someone with an infection affects guests and staff.
This is the solution;
Efficiently and economically deploy this fever screening thermal camera to auto-detect and alert staff of any high skin temperature individuals entering. With extremely high accuracy levels of 0.6°F (0.3°C), you don't have to worry about wrong readings and focus on your business.
Check out our infographic explaining the advantages of using a thermal camera for fever screening.
-
- Thermal Resolution: 32 x 32, 1024 pixels, Camera and Video Recording, 9Hz Refresh Rate
- Touch screen: Real-time temperature information from any pixel on the screen
- Thermal Sensitivity: 0.15°C, Body Temperature Range:
- Human Mode: 32°C~42°C (89.6°F~107.6°F), Accuracy: ± 0.3°C (± 0.6°F)
- Industrial Mode: -30 to 1000 °C (-22 to 1832 °F) , Accuracy: ±2 % or ± 2 °C
- Thermal Radiometry data included for full report analyses, CSV format, compatible with thermal software
- Based on the Android platform: Update firmware conveniently at home and experience smoother operations all around.
-
Specification Description Infrared Image resolution 32 x 32 (1,024 Pixels) Visible Image resolution 0.2 Mega Pixels Field Angle/Shortest focus length 33° x 33°/0.1m Human Mode Temperature Range 89.6°F~107.6°F (32°C~42°C) Industrial Mode Temperature Range -22 to 1832 °F (-30 to 1000 °C) Measuring Accuracy for Human Mode ± 0.6°F (± 0.3°C) Measuring Accuracy for Industrial Mode ±2 % or ± 2 °C Emissivity Adjustable from 0.01 to 1.0 Display screen 2.8" LCD Color Display Spectral Range 8-11.5um Image Frequency 9Hz Focus mode Fixed Color Palettes 9 Options View option Full Infrared and Full Vision Thermal Overlay with 25% Increment Storage Medium 1GB Internal Memory + 16GB SD Card Included Image format BMP, JPG, MP4 Power Supply 3.7V Lithium-ion Chargeable Battery 2500mAh, Size 18650 USB Mini USB Auto-Power off Time Selectable from 0 to 30 mins Product size(length x width x height) 215 x 55 x 62 mm Product Weight 230g Work temperature -10 to 50°C Storage temperature -20°C -60°C -
60 Days Money-Back Guarantee
To make sure our customers are satisfied with our products, we are happy to offer a 60 days Money-Back Guarantee. If for any reason you are not completely satisfied, return the product for a full refund.
Just drop us an email at cs@perfectprime.com for more details about our 60 Days Money-Back Guarantee.
-
Download User (English) Manual
Download User (Japanese) Manual
- Looking to purchase in bulk? We offer bulk purchase discounts for most products on orders with a minimum of 10 units. The higher the volume, the bigger the discount. Contact us for more details here: Business Contact Form.
Customer Reviews
Human

This thermal camera was designed and calibrated specifically for human use. In comparison to non contact thermometers it takes into account all thermal signatures within its line of sight, presented on the screen. Having analysed all this data, the sensor will auto detect the hottest point available.

Distance

Being able to safely monitor elevated human body temperature in individuals entering buildings is paramount to preventing the spread of viruses. Keeping a 2 meter distance is highly advised but many non contact laser thermometers are only accurate when used within 50mm (5 cm), making it extremely dangerous for the user being exposed if someone does have the virus.
The IR0280H can be used up to 2 meters away and still be extremely accurate. This greatly reduces the risk of potential infection for users and other individuals as they are also scanned instantly so that staff may pull them aside for further screening.
Stand

Being a handheld thermal camera has the advantages of being mobile and quick to deploy in different environments. At the same time, this model has a tripod mount hole at the bottom enabling it to be set into place for continuous surveillance.
Accuracy

Standard handheld thermal cameras have an accuracy of 2°C which if interpreted at the maximum ends can lead to missing individuals who have a high temperature. The IR0280H has been calibrated to be within 0.3°C accuracy which eliminates most of the potential of failing to accurately spot an individual with a fever.

alarm

Whether the thermal camera is deployed as a static camera or handheld, the user can set an alarm to sound whenever a detected temperature is at fever level. Monitor a continuous flow of people walking past with confidence that the thermal camera will catch anyone with a feverish temperature.
SPECIFICATIONS
Display
Infrared Image Resolution
Visible Image Resolution
Field Angle / Shortest Focus Length
Body Temperature Range
Measuring Accuracy
Emissivity
Image Frequency
Focus Mode
Color Palettes
View Option
Spectral Range
Storage Medium
Image Format
Power Supply
USB
Auto-Power off Time
Product Size (Length x Width x Height)
Product Weight
Work Temperature
Storage Temperature
2.8" Color LCD Display
32 x 32 (1,024 Pixels)
0.2 Mega Pixels
33° x 33°/0.1m
32°C~42°C (89.6°F~107.6°F)
± 0.3°C (± 0.6°F)
Adjustable from 0.01 to 1.0
9Hz
Fixed
9 Options
Full Infrared and Full Vision
Thermal Overlay with 25% Increment
8-11.5um
1GB Internal Memory + 16GB SD Card Included
BMP, JPG, MP4
3.7V Lithium-ion Chargeable Battery
2500mAh, Size 18650
Mini USB
Selectable from 0 to 30 mins
215 x 55 x 62 mm
230g
-10 to 50°C
-20 to 60°C
Customer Reviews
SPECIFICATIONS
Display
Infrared Image Resolution
Visible Image Resolution
Field Angle / Shortest Focus Length
Body Temperature Range
Measuring Accuracy
Emissivity
Image Frequency
Focus Mode
Color Palettes
View Option
Spectral Range
Storage Medium
Image Format
Power Supply
USB
Auto-Power off Time
Product Size (Length x Width x Height)
Product Weight
Work Temperature
Storage Temperature
2.8" Color LCD Display
32 x 32 (1,024 Pixels)
0.2 Mega Pixels
33° x 33°/0.1m
32°C~42°C (89.6°F~107.6°F)
± 0.3°C (± 0.3°F)
Adjustable from 0.01 to 1.0
9Hz
Fixed
9 Options
Full Infrared and Full Vision
Thermal Overlay with 25% Increment
8-11.5um
1GB Internal Memory + 16GB SD Card Included
BMP, JPG, MP4
3.7V Lithium-ion Chargeable Battery
2500mAh, Size 18650
Mini USB
Selectable from 0 to 30 mins
215 x 55 x 62 mm
230g
-10 to 50°C
-20 to 60°C
HUMAN
This thermal camera was designed and calibrated specifically for human use. In comparison to non contact thermometers it takes into account all thermal signatures within its line of sight, presented on the screen. Having analysed all this data, the computer will auto detect the hottest point available.

Distance
Being able to safely monitor elevated human body temperature in individuals entering buildings is paramount to preventing the spread of viruses. Keeping a 2 meter distance is highly advised but many non contact laser thermometers are only accurate when used within 50mm (5 cm). Making it extremely dangerous for the user being exposed if someone does have the virus.
The IR0280H can be used up to 2 meters away and still be extremely accurate. This greatly reduces the risk of potential infection for users and other individuals as they are also scanned instantly so that staff may pull them aside for further screening.

Stand
Being a handheld thermal camera it has the advantages of being mobile and quick to deploy in different environments. At the same time, this model has a tripod mount hole at the bottom enabling it to be set into place for continuous surveillance.

accuracy
Standard handheld thermal cameras have an accuracy of 2°C which if interpreted at the maximum ends can lead to missing individuals who have a high temperature. The IR0280H has been calibrated to be within 0.3°C accuracy which eliminates most of the potential of failing to accurately spot an individual with a fever.


alarm
Whether the thermal camera is deployed as a static camera or handheld, the user can set an alarm to sound whenever a detected temperature is at fever level. Monitor a continuous flow of people walking past with confidence that the thermal camera will catch anyone with a feverish temperature.

SPECIFICATIONS
Display
Infrared Image
Resolution
Visible Image
Resolution
Field Angle / Shortest Focus Length
Body Temperature Range
Measuring Accuracy
Emissivity
Image Frequency
Focus Mode
Color Palettes
View Option
Spectral Range
Storage Medium
Image Format
Power Supply
USB
Auto-Power off Time
Product Size (Length x Width x Height)
Product Weight
Work Temperature
Storage Temperature
2.8" Color LCD Display
32 x 32
(1,024 Pixels)
0.2 Mega Pixels
33° x 33°/0.1m
32°C~42°C (89.6°F~107.6°F)
± 0.3°C (± 0.3°F)
Adjustable from 0.01 to 1.0
9Hz
Fixed
9 Options
Full Infrared and Full Vision
Thermal Overlay with 25% Increment
8-11.5um
1GB Internal Memory + 16GB SD Card Included
BMP, JPG, MP4
3.7V Lithium-ion Chargeable Battery
2500mAh,
Size 18650
Mini USB
Selectable from 0 to 30 mins
215 x 55 x 62 mm
230g
-10 to 50°C
-20 to 60°C
