IR5000 Face Recognition with Thermal Sensor System
TVT500 Facial Recognition Terminal for Temperature Measurement
The face recognition terminal for temperature measurement is an access control product that provides face recognition and infrared array thermal imaging technologies. Powered by Android, the product is non-contact, high accuracy, high security and good stability.
- Supports face detection and recognition
- Supports mask detection
- Supports body temperature detection
- Supports one-click installation and deployment of web services
- Supports recognition distance configuration
Specification Description Thermal imaging resolution
4 x 4 array Thermal imaging perspective (FOV) 27º Temperature measurement range 30-45°C Temperature measurement distance 0.5m Temperature measurement accuracy ±0.5°C ideal indoor
Identification card type
Read M1IC card serial number and ID card serial number
RF operating frequency 13.56MHZ Operating effective distance <3cm Reading rate 15 times/second Working temperature +20°C - +35°C Working humidity 10-90% relative humidity, no condensation Power supply DC12V/3A Equipment power consumption ≤25W Equipment size
250*142*22mm (height*width*thickness) Equipment weigh 1.2 kg (depending on configuration) Camera Binocular MIPI B/W, HDR 2 million pixel camera, automatic exposure, automatic white balance, and automatic backlight optimization Sensor 1/2.7” industrial-grade binocular high-definition wide-dynamic-range image sensor Frame rate Maximum 30 frames in black, white and color, no ghosting Infrared light spectrum 850nm Effective pixels 1920*1080/1920*1080 Lens
M12(f=3.6MM)/ M12(f=3.6MM) Pixel size 3.0um X3.0um/3.0um X3.0um Minimum illumination ≥0.01LUX at F1.2/≥0.1LUX at F1.2 Signal to noise ratio ≥41dB Wide dynamic range ≥96dB/≥105dB Interface type USB2.0 Video coding H.265 Main Profile coding/H.264 BP/MP/HP coding/MJPEG coding Image resolution
640X480@ 30fps /800X600@ 30fps /1280X720@ 30fps/1280X1024@
30fps/1920X1080@ 30fps /1600X1200@ 15fps /2048X1536@ 15fps
640X480@ 30fps /800X600@ 20fps /1280X720@ 5fps/1280X1024@
5fps/1920X1080@5fps /1600X1200@ 5fps /2048X1536@ 3fps
60 Days Money-Back Guarantee
To make sure our customers are satisfied with our products, we are happy to offer a 60 days Money-Back Guarantee. If for any reason you are not completely satisfied, return the product for a full refund.
Just drop us an email at firstname.lastname@example.org for more details about our 60 Days Money-Back Guarantee.
Download User Manual(English)
- Looking to purchase in bulk? We offer bulk purchase discounts for most products on orders with a minimum of 10 units. The higher the volume, the bigger the discount. Contact us for more details here: Business Contact Form.
